8 Band Backpack Style Drone Suppressor With Directional Antenna 360W Power Consumption
  • name
  • name
  • name
  • name
  • name

8 Band Backpack Style Drone Suppressor With Directional Antenna 360W Power Consumption

MOQ: 1pcs
Delivery Period: 7-14 days
Payment Method: T/T
Detail Information
Product Description
Detail Information
Brand Name
ttsk
Model Number
TTSKM02
Document
TTSKM02.8-Band Backpack-sty...r.docx
400-470MHz:
47dBm
480-525MHz:
47dBm
850-940MHz:
47dBm
1160-1280MHz:
47dBm
1550-1620MHz:
47dBm
2380-2500MHz:
45dBm
5150-5350MHz:
47dBm
5700-6000MHz:
45dBm
Highlight:

8 Band Drone Suppressor

,

Backpack Style Drone Suppressor

,

360W backpack drone jammer

Product Description
8-Band Backpack-style Drone Suppressor with Directional Antenna and 360W Power Consumption
Model No: TTSKM02
Product Characteristics
  • Using UHF broadband seamless jamming technology
  • Single switch control output, with battery power display
  • The higher the effective power (channel power), the greater the interference distance
  • Effective segmentation, only interferes with drone control and video transmission frequencies without affecting other frequencies
  • Imported devices with slow start circuit design to avoid ignition phenomenon caused by mechanical switch
  • Built-in battery with approximately 1 hour operation time and 6 hours charging time
  • 8 SMA/N type directional antenna interfaces (400M / 500M / 900M / 1.2G / 1.5G / 2.4G / 5.2G / 5.8G)
  • One power charging interface (DC28V IN)
Product Parameters
Frequency (Customizable) Working Frequency dBm Output Power
433MHz 400-470MHz 47dBm 50W
500MHz 480-525MHz 47dBm 50W
900MHz 850-940MHz 47dBm 50W
1.2GHz 1160-1280MHz 47dBm 50W
1.5GHz 1550-1620MHz 47dBm 50W
2.4HGz 2380-2500MHz 45dBm 30W
5.2GHz 5150-5350MHz 47dBm 50W
5.8GHz 5700-6000MHz 45dBm 30W
Power Supply: AC220V-DC24V
Omnidirectional countermeasures range: 500-1500 meters
Power Consumption: 360W
Weight: 16kgs
Size: 370*240*510mm
Product Operation Instructions
Precautions
  • Connect the antenna and tighten it before use
  • Connect the handle one by one - battery power display shows number of batteries inside
  • Enable fan heat dissipation system during operation
  • Device is configured with both 28V DC and 220V AC - verify carefully before use
  • Avoid misconnection to prevent burning modules
Use Process
  • Forced landing of DJI drones: Open 1.5G, 2.4G, 5.8G
  • Forced returning DJI drones: Open 2.4G, 5.8G
  • Forced landing of lane passing drones: Open 1.5G, 2.4G, 5.2G, 5.8G
  • Forced returning the passageway UAV: Open 2.4G, 5.2G, 5.8G
  • 400M remote control: Frequency band for homemade drones, TV remote control, car keys, etc.
  • 900M remote control: Commonly used for industrial drones, Police level, and large class drones
  • 1.2G: China's Beidou navigation system frequency, future use in UAV industry
Note: Charge the device once every half month to maintain battery performance.
Technical Note: The interference power is certain, and the shielding radius is determined by path attenuation and control remote transmission signal level. The coverage radius can be determined by the output channel power, remote control signal level and coverage line gain.
Distance And Attenuation Comparison Table
Distance (m) 900MHz attenuation (dB) 1575MHz attenuation (dB) Distance (m) 2400MHz attenuation (dB) 5800MHz attenuation (dB)
1 38 44 25 66 72
2 44 50 30 67.5 73.5
3 48 54 35 69 75
4 50 56 40 70 76
5 52 58 45 71 77
Antenna Usage Guidelines
8 Band Backpack Style Drone Suppressor With Directional Antenna 360W Power Consumption 0
  • Connect antenna before switching on power - never remove antenna during operation
  • Place equipment in well-ventilated area with minimal obstruction
  • Use waterproof protection outdoors and avoid direct sunlight
  • Point antenna vertically towards the drone for optimal effect
Frequently Asked Questions
Q1: Is drone countermeasure equipment harmful to human body and mobile phone?
A: The emitted electromagnetic signal intensity is very weak and poses no danger to human body. The equipment only interferes with forward signals to prevent contact between UAV and remote control, without damaging the UAV itself.
Q2: Is there a difference in distance between indoor and outdoor use of drone countermeasures equipment?
A: Yes, outdoor signals typically perform better. The effective working distance depends on electromagnetic environment and surrounding conditions including distance and location.
Q3: The case heats up after working for a period of time. Will it damage the machine if working for a long time?
A: This is normal. The all-aluminum housing design assists in heat dissipation, allowing stable long-term operation without damage to the machine.
